Digital Spline Micrometer IP65 Inch/Metric, 2-3", 2mm Measuri
Stock Code: MIT331-363
£611.10 (exc VAT) Each Includes your 15% Disc
£733.32 (inc VAT)
Next Day Delivery
Mitutoyo 331-363 Digimatic Spline Micrometer This Digimatic Disc Micrometer allows you to measure a range of different materials. It offers you the following benefits: Non-rotating spindle and disc-shaped measuring surfaces. Measuring the root tangent length of spur and helical gears Measurable range of gear pitch: 0,5-6 module. Suitable for measuring felt, rubber, cardboard, fabric etc.
| Range: |
2 - 3 inch
|
| Anvil/ Tip: |
B
|
| Accuracy: |
±2 µm/0.0001"
|
| Mass: |
625 g
|
| Measuring force: |
5 - 10 N
|
| Digital step: |
0,001 mm
|
| Scale: |
Thimble and sleeve satin chrome finish, ø18 mm
|
| Flatness: |
0,3µm/0.000012"
|
| Parallelism: |
(2+L/100) µm, L = max. range (mm) [0.00008" + 0.00004 (L/4)]" L = max. range (inch)
|
| Measuring surfaces: |
Carbide tipped, micro-lap finish, stepped
|
| Measuring spindle: |
ø6,35 mm, Spindle pitch 0,5 mm, with spindle lock
|
| Battery life: |
approx 2.4 years
|
| Delivered: |
Including box, setting standard (from 25 mm upward), key, 1 battery
|
| ORIGIN: |
Yes
|
| ZERO/ABS: |
Yes
|
| Auto Power OFF after 20 min. non use: |
Yes
|
| Function lock: |
No
|
| Data output: |
Yes
|
| HOLD: |
Yes
|
| Digital/Analog: |
Digital
|
| Inch-Metric: |
Inch/Metric
|
