Blade Micrometer, Carbide-Tipp 0-25mm, 0,4mm Blade
Stock Code: MIT122-141
£242.51 (exc VAT) Each Includes your 15% Disc
£291.01 (inc VAT)
Next Day Delivery
Mitutoyo 122-141 Blade Micrometer This Digimatic Disc Micrometer allows you to measure a range of different materials. It offers you the following benefits: Non-rotating spindle and disc-shaped measuring surfaces. Measuring the root tangent length of spur and helical gears Measurable range of gear pitch: 0,5-6 module. Suitable for measuring felt, rubber, cardboard, fabric etc.
| Range: |
0 - 25 mm
|
| Anvil/ Tip: |
D
|
| Accuracy: |
±3 µm
|
| Mass: |
275 g
|
| Measuring force: |
3 - 8 N
|
| Graduation: |
0.01 mm
|
| Parallelism: |
3 µm for models up to 75 mm (3+L/100) µm for models over 75 mm, L= max. range (mm)
|
| Measuring spindle: |
ø 8 mm, spindle pitch 0,5 mm
|
| Delivered: |
Including box, setting standard (from 25 mm upward), key
|
| Inch-Metric: |
Metric
|
No detailed specifications are available for this product.
There are no downloads for this product.
There are no reviews for this product yet. Be the first to add one!
